| Model No | Power | Body & Finish | Voltage | CCT | CRI | PF | Beam Angle | Rated Luminous Flux | Working Temperature | Rated Life | Body Dimension ØxH (mm) | Ceiling Cutout Dimension Ø (mm) | IP Rate |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| EL-06RDL | 06W | Aluminum & PC Diffuser | AC90V-300V | 2700K-6500K | >80 | >0.95 | 120° | 330 | -20° C to 45° C | 40000 Hours | 135x50 | 115 | IP20 |
| EL-09RDL | 09W | Aluminum & PC Diffuser | AC90V-300V | 2700K-6500K | >80 | >0.95 | 120° | 550 | -20° C to 45° C | 40000 Hours | 145x50 | 125 | IP20 |
| EL-12RDL | 12W | Aluminum & PC Diffuser | AC90V-300V | 2700K-6500K | >80 | >0.95 | 120° | 770 | -20° C to 45° C | 40000 Hours | 168x50 | 138 | IP20 |
| EL-15RDL | 15W | Aluminum & PC Diffuser | AC90V-300V | 2700K-6500K | >80 | >0.95 | 120° | 990 | -20° C to 45° C | 40000 Hours | 180x70 | 140 | IP20 |
| EL-18RDL | 18W | Aluminum & PC Diffuser | AC90V-300V | 2700K-6500K | >80 | >0.95 | 120° | 1320 | -20° C to 45° C | 40000 Hours | 180x70 | 140 | IP20 |
| EL-24RDL | 24W | Aluminum & PC Diffuser | AC90V-300V | 2700K-6500K | >80 | >0.95 | 120° | 1650 | -20° C to 45° C | 40000 Hours | 195x70 | 150 | IP20 |
